Dimensional Control & Scanning

Dimensional Control is essentially the accurtate measurement of 3 dimensional spaces or objects. It enables us to digitise, model and analyse the area or item surveyed and compare it to another object or its own design.

Dimensional Control originated in the offshore petroleum industry but is now also used onshore across a range of industries such as mining, engineering, manufacturing, marine and aeronautical.

services_rig

Applications

  • 3D data capture
  • Clash detection
  • Equipment alignment
  • Equipment fabrication
  • Structural monitoring

Benefits

  • Safety
  • Re-work prevention
  • Reduce installation times
  • Eliminate clashing
  • Minimise hotworks
  • Reduce wear and tear
services-survey-pipes

Survey Methodolgy

Infrared laser

  • No access ladders, working at heights or scaffolding required.
  • Ability to survey in the most congested areas accurately.

Laser scanning

  • Point cloud data exportable directly to most design softwares.
  • Highly detailed models.
services-port

Leica Truview

  • Web based system allowing clients to view data that has just been captured.
  • Enables client to mark up the scans, check coordinates, take measurements and submit TQ to us while we are still onsite.
  • Allows engineering professionals to view the site without
    having to mobilise to site.
  • Ensures all required data is captured before departing the platform or site.
  • It’s complimentary.
